Core Functions & Applications
Infection Control: Create airtight isolation zones for contagious disease management.
Critical Care Units: Serve as ICU pods for vulnerable patients.
Modular Flexibility: Function as standalone isolation units or connect to larger mobile hospitals.
Field Accommodation: Provide secure, single-occupancy shelters for medical staff or patients.
Ideal for pandemics, disaster relief, military operations, and remote clinics, the Low Pressure Inflatable Isolation Tent ensures compliance with global biosafety standards.
Key Advantages Over Conventional Shelters
| Feature | Our Tent | Traditional Tents |
|---|---|---|
| Deployment Time | 3–5 minutes | 15–30 minutes |
| Weight | 65kg (ultra-portable) | 120–150kg |
| Pressure Resistance | 70kPa limit (3x industry average) | ≤25kPa limit |
| Weatherproofing | Level 8 wind + 150kg/m³ rain resistance | Level 6 wind + 80kg/m³ rain |
Technical Specifications
1. Precision Engineering
Dimensions:
Projection: 4.4m (L) × 3.4m (W) × 3m (H) | 15㎡ footprint.
Internal Space: 4m (L) × 3m (W) × 2.8m (H) | 12㎡ usable area.
Pressure System:
Operating Range: 18–22kPa (optimized for airflow control).
Safety Margin: Withstands up to 70kPa (emergency scenarios).
2. Medical-Grade Materials
Outer Canopy: Medical white Oxford cloth (450g/m², 0.42mm thick; 9,000–10,000mm hydrostatic resistance; 1,270N/5cm warp / 1,330N/5cm weft tensile strength).
Inner Liner: White silk-like polyester fabric (lightweight, non-porous surface).
Air Columns: Airtight PVC-coated mesh (760g/m², 0.72mm thick; 2,400N/5cm warp / 2,000N/5cm weft strength; 130N peel resistance).
Base Mat: Reinforced gray PVC mesh (non-slip, chemical-resistant).
3. Safety & Usability
Access Points:
2×1.5m wide doors (2m height) + 4×0.895m × 0.695m windows.
2×1.6m connector corridors for modular expansion.
Climate Resilience: Operates from -40°C to +70°C.
Visibility: Pre-printed 500mm × 500mm red cross symbols (2 sets) + customizable door logos.
Deployment Process
Site Prep: Select flat terrain (concrete, sand, or non-abrasive grass).
Unfold & Inflate: Use electric pumps to reach 18–22kPa in 3–5 minutes.
Secure: Anchor with ground stakes and tighten anti-collapse ropes.
Connect: Attach corridors to adjacent hospital modules or power/ventilation systems.
Why Choose Our Low Pressure Inflatable Isolation Tent?
Biosafety Compliance: Airtight seams + PU tape reinforcement prevent pathogen leakage.
Ultra-Portable: 65kg weight + 0.7m × 0.55m × 0.55m pack size (fits standard vehicles).
Rapid Reconfiguration: Switch between isolation, ICU, or accommodation modes in minutes.
Global Readiness: Meets WHO/ICRC standards for emergency medical shelters.
Critical Use Cases
Pandemic Response: Isolate COVID-19, Ebola, or airborne pathogen cases.
Field Hospitals: Deploy ICU pods during earthquakes or conflict zones.
Remote Clinics: Protect immunosuppressed patients in resource-limited areas.
Packaging and Shipping
PVC bag or wooden box packaging.
Support sea transportation, land transportation and air transportation.
