Core Functions & Applications
Reception & Intake Zone: Streamline patient registration and prioritization.
Initial Assessment: Conduct rapid evaluations and stabilize urgent cases.
Operational Coordination: Direct resources, manage logistics, and track data.
Mobile Command Hub: Serve as an administrative center for field teams.
Ideal for disaster response, public health campaigns, military operations, and remote healthcare, the Low-Pressure Inflatable Reception Tent delivers adaptable support in resource-limited environments.
Key Features
1. Rapid, Safe Deployment
15-Minute Setup: Fully operational within 10–15 minutes using low-pressure inflation.
Stable Structure: Maintains rigidity for ≥7 days post-inflation.
Weather Resilience: Withstands Level 8 wind loads and 100–150mm surface water exposure.
2. Medical-Grade Durability
Modular Design: 5 components-Air Ribs (structural frame), outer canopy, inner liner, base mat, and connector corridors.
High-Strength Materials:
Outer Canopy: Medical-grade white Oxford cloth (1,270N/5cm warp / 1,330N/5cm weft tensile strength).
Inner Liner: White silk-like polyester fabric (0.12mm thickness).
Air Ribs: Airtight PVC-coated mesh (760g/m², 0.72mm thick; 2,400N/5cm warp / 2,000N/5cm weft strength).
Base Mat: Gray PVC-coated mesh (600g/m², 0.55mm thick).
3. Optimized for Versatile Workflows
Spacious Layout:
Projection: 10.35m (L) × 5.8m (W) × 3.6m (H) | 60㎡ area.
Internal Space: 9.69m (L) × 5.14m (W) × 3.27m (H) | 50㎡ usable area.
Access & Ventilation:
4 wide doors (1.5m × 2m) + 6 windows (0.895m × 0.695m).
4 connector corridors (1.6m × 2.15m) for modular expansion.
8 pre-installed temperature-controlled vents.
Visibility: Pre-printed 500mm × 500mm red cross symbols on the canopy.
Technical Specifications
| Component | Details |
|---|---|
| Packaging | Silicone-coated canvas + waterproof outer bag (1m × 1m × 0.9m; 270kg total weight). |
| Inflation | Compatible with electric or manual pumps. |
| Safety | Flame-retardant, UV-resistant, and anti-collapse anchor kits. |
Why Choose Our Low-Pressure Inflatable Reception Tent?
Speed: Deploy 3x faster than traditional tents.
Adaptability: Transition effortlessly between medical intake, administrative tasks, and command operations.
Portability: Compact storage design reduces transport costs.
Compliance: Meets rigorous medical, safety, and durability standards.
Critical Scenarios
Disaster Relief: Instant field clinics for patient intake post-earthquakes, floods, or storms.
Public Health Campaigns: Vaccination stations, health screenings, or community outreach hubs.
Military & Aid: Centralized coordination units in conflict zones or refugee camps.
