Key Features
Rapid Deployment: Fully inflates in 10–15 minutes and maintains stable pressure for ≥7 days.
Spacious Design: 90㎡ footprint (77㎡ usable space), with a 4m peak height for ample headroom.
Durable Construction: High-strength materials ensure weather resistance and long-term use.
Modular Connectivity: Includes 4 connection corridors (1600mm × 2150mm) for seamless integration with other units.
Technical Specifications
Structure & Materials
Frame: Low-pressure air beams made of knife-coated, airtight PVC laminated mesh fabric.
Outer Cover: Medical-grade white oxford fabric (450g/㎡, 0.42mm thick).
Inner Liner: White polyester (72g/㎡, 130N peel strength).
Floor: Heavy-duty gray PVC mesh fabric (600g/㎡, 0.55mm thick, 1800N/5cm warp tensile strength).
Dimensions
Projection Size: 12.45m (L) × 7.25m (W) × 2.3m (shoulder height) × 4m (peak height).
Internal Size: 11.79m (L) × 6.59m (W) × 2.1m (shoulder height) × 3.67m (peak height).
Doors, Windows & Ventilation
Doors: 4 × (1500mm × 2000mm).
Windows: 8 × (895mm × 695mm).
Ventilation: 8 × HVAC ports , 2 × air valves, 2 × cable entry ports.
Weather & Load Resistance
Rainproof: Withstands ≥100mm/h rainfall (150kg/m³).
Groundwater Protection: 100–150mm raised floor design.
Terrain Adaptability: Suitable for concrete, sand, compacted soil, and grass (without sharp debris).
Portability & Storage
Weight: 405 kg.
Packaging: Silicone-coated canvas bag + waterproof woven outer sleeve (1.1m × 1.1m × 1m).
Why Choose Our Low-Pressure Inflatable Restaurant Tent?
✅ Fast Setup – Operational in minutes, ideal for emergency deployments.
✅ Modular Flexibility – Connects seamlessly with inflatable mobile hospitals and command units.
✅ Military-Grade Durability – Reinforced seams, heat-welded joints, and UV-resistant fabrics.
✅ All-Weather Performance – Engineered for heavy rain, wind, and varying terrains.
Applications
Field Kitchens & Restaurant Halls (Military, Disaster Relief)
Mobile Hospital Support Tents (Restaurant, Command Centers)
Expedition Camps & Event Shelters
Request a Quote Today! Equip your team with the most reliable low-pressure inflatable restaurant tent on the market.
Packing and Delivery
PVC bag or wooden box packaging.
Support sea transportation, land transportation and air transportation.
Welcome to contact us, our email is jinsail@jinsail.com, we will reply to you as soon as possible.
