Modular Structure
The Inflatable Temporary Hospital Tent integrates 5 core elements:
Airbeam Frame: High-pressure inflatable columns for rigid support.
Outer Canopy: Weatherproof shield with UV/water resistance.
Inner Liner: Breathable layer for thermal and hygienic control.
Base Mat: Anti-slip, insulated flooring.
Connecting Corridor: Enables seamless attachment to other medical units.
Technical Specifications
Projection Size: 11.9m (L) × 3.9m (W) × 2.3m (Shoulder Height) × 3.3m (Peak Height).
Projection Area: 46.41㎡.
Internal Size: 11.4m (L) × 3.4m (W) × 2.1m (Shoulder Height) × 3m (Peak Height).
Usable Area: 38.76㎡.
Premium Materials
Outer Canopy: Medical white Oxford fabric (custom colors available).
Weight: 450g/㎡ | Thickness: 0.42mm | Hydrostatic Pressure: 9000–10000mm.
Inner Liner: White "Shumei" silk (customizable).
Weight: 72g/㎡ | Thickness: 0.12mm.
Air Columns: Knife-coated PVC mesh fabric.
Base Mat: Gray PVC mesh fabric.
Key Features
✔ Ultra-Fast Setup: Ready for use within minutes.
✔ Hospital-Grade Protection: Waterproof, windproof, and antimicrobial materials.
✔ Customizable Design: Color options for outer/inner layers.
✔ Scalable System: Connect multiple Inflatable Ward Tents for expanded capacity.
Ideal for disaster response teams, military medical units, and temporary hospitals, the Inflatable Ward Tent ensures safe, efficient patient care anywhere. Contact us for OEM/ODM solutions!
Packing and Delivery
