Products Description
The 1000m² High-Pressure Inflatable Hangar Tent is engineered with a large-span air-inflated structural system and covered with durable, flexible outer fabric. It provides a secure, weather-protected space for storing aircraft, military vehicles, and mission-critical equipment,Interior Area 960m2.
The hangar integrates seamlessly with camouflage netting, electromagnetic shielding fabrics, and thermal insulation liners, enabling infrared camouflage, radar reduction, and improved environmental control ,depending on the specific application requirements. Designed for rapid deployment in diverse terrains, it ensures equipment concealment and offers a safe, stable working environment.
Technical Specifications
Air Rib Material - Physical & Mechanical Properties
Puncture Resistance: ≥1000 N
Maximum Pressure: ≥0.6 MPa
Environmental Adaptability
| Performance | Specification |
|---|---|
| Operating Temperature | -43°C ~ +50°C |
| Storage Temperature | -55°C ~ +70°C |
| Waterproof | ≥2 mm/min rainfall, 3h no leakage, 5h no dripping |
| Salt Fog Resistance | 150 h, no discoloration, no cracks |
| Damp Heat Resistance | ≤ Level 2 |
| Snow Load | 100 mm loose snow |
| Wind Load | ≥28.4 m/s (Level 10 wind) |
Thermal Insulation System
1. Thermal control is achieved through:
2. Outer tent fabric
3. Inner insulation liner
4. Air buffer layer between 2. and 3.
5. Optional heating system / HVAC
Ensures stable interior temperature in cold or hot climates.
Deployment & Operations
1. Setup Time: ≤12h with 16 personnel
2. Takedown Time: ≤12h with 16 personnel
Maintenance & Reliability
One-time inflation keeps working pressure for ≥90 days
Routine repair operations ≤ 0.5h
Comes with full professional repair toolkit
Reserved system interfaces for future upgrades (camouflage, electricity, HVAC, sensors)
Key Features
1. Large-Span High-Pressure Inflatable Structure
Supports wide-span buildings without rigid metal beams
High-pressure air ribs provide superior strength and stability
Maximum working pressure ≥ 0.6 MPa
2. All-Weather Protection
Operating temperature: -43°C ~ +50°C
Storage temperature: -55°C ~ +70°C
Waterproof: ≥2 mm/min rainfall, 3h no leakage
Wind resistance: ≥28.4 m/s (Level 10)
Snow load: 100 mm loose snow
3. Multi-Functional Integration
Camouflage & stealth (IR suppression, radar reduction)
Thermal insulation via liner + air layer
Supports heaters, HVAC, power distribution, and lighting systems
Compatible with military or civil emergency systems
4. Quick Deployment & Mobility
Setup ≤12 hours (16-person team)
Takedown ≤12 hours
Fully inflatable system, no heavy cranes required
5. Excellent Durability & Reliability
One-time inflation maintains working pressure for ≥90 days
Service life ≥5 years
High puncture resistance: ≥1000 N
Salt fog resistance: 150h with no cracks or fading
Applications
1. Aircraft / Helicopter Hangar
2. Equipment Maintenance Shelter
3. Military Field Command Tent
4. Mobile Medical Facility
5. Temporary Barracks / Accommodation
6. Field Warehouse or Storage Facility
7. Dining Hall & Logistics Support Unit
8. Disaster Relief Operations Shelter
FAQ
1. How long does the hangar stay inflated?
With one-time inflation, it maintains working pressure for 90 days or longer.
2. Can the hangar withstand strong wind or snow?
Yes. It resists Level 10 wind (28.4 m/s) and 100 mm loose snow load.
3. Can it be used in desert, plateau, or coastal areas?
Absolutely. It is designed for salt-fog, high temperature, low temperature, humidity, and sand conditions.
4. Can it be equipped with HVAC, lights, and power?
Yes, it supports full interior integration.
5. Do you accept customization?
Yes. Size, color, camouflage, EMC shielding, and structure can all be customized.
Packing and Delivery
1. Secure Packaging: Products are packed in standard export cartons or pallets to prevent damage.
2. Flexible Shipping: Choose sea, air, or land transport to meet your schedule.
3. Timely Delivery: Fast and reliable logistics to your location.
Dimension Weight
Length 58m* Width 35m* Height 13.4m
Physical and mechanical properties of air-ribbed materials
Anti-puncture performance: ≥1000N
Environmental adaptation
1) Temperature resistance: working temperature: -43℃~+50℃; storage temperature: -45℃~+70℃.
2) Waterproofing: rainfall intensity ≥2mm/min, 3h without leakage, 5h without dripping;
3) Load resistance: can withstand 100mm of light snow.
4) Wind resistance: able to withstand strong winds with a wind speed of ≥ 20.7m/s (level 8)
Assemble& Disassemble Time
Assemble time ≤ 12 h (16 persons); disassemble time ≤ 12 h (16 persons)
Reliability
One-time inflation can maintain working for ≥ 180 days, with a service life of no less than 5 years.
